7*14 Inch Metal Lathe 700W Brushless Motor 2500RPM Mini Bench Lathe Variable Spindle Speed Lathe Machine (62359745345)

Share on:


Price:$490.00 - $530.00
Price in USD:Details

Quantity:


Product Overview

Description


7*14 Inch Metal Lathe 700W Brushless Motor 2500RPM  Mini Bench Lathe Variable Spindle Speed Lathe Machine


Introduction


The mini lathe is designed to perform various types of processing jobs. Counterface turning, drilling, threadinfg and cutting jobs on materials made up of round bar and bar materials can be performed with this machine. This machine can be used in areas such as mini precision parts processing, sample processing and modeling works.



Model Specification


























































































Specification0618*350mm
Swing over bed180mm
Swing over cross slide110mm
Distance between centers350mm
Width of bed100mm
Spindle bore32mm
Spindle taperMT3
Spindle speed:50-2500rpm
Number of metric threads9
Range of spindle speed0.5-2.5mm
Tool post type4
Max compoud slide way35mm
Max carriage slide travel65mm
Max carriage travel195mm
Tailstock travel40mm
Tailstock taperMT2
Main motor




700W Brushless Motor


Voltage220V/110V
Dimension(mm)750*315*305
Weight50kg
