Gyms fitness center factory big air BLDC Motor VFD controlled floor standing mobile HVLS fans

Product Overview

Description

Gyms fitness center factory big air BLDC Motor VFD controlled floor standing mobile HVLS fans



The Mobile HVLS Fan is equipped with brushless DC motor and high strength aircraft grade magnalium blades .It can be moved easily indoors and outdoors with 4 wheels .

Meanwhile, the fan adopts PMSM motor to drive the fan blade, which can produce large and continuous air. the effective air supply distance of the Mobile HVLS fan is up to 30m and the coverage area can be 300 m2. The entire steel frame of the fan is integrated designed, sturdy and durable, so it can be used in most of places with complicated situations. It is a kind of fan with high volume and low speed which is widely used indoors or outdoors, not only to ventilate and cool, but also to be a portable wind source to feel the cooling everywhere.



Main feature :



1. Super large air volume: Ultra-long air blowing, the effective distance is more than 30m;
2, Move easily: Designed with 4 wheels, the fan is able to move everywhere easily;
3, Energy saving: With only 0.9KW power, very low energy consumption;
4, Quiet and Low noise: Low noise with only 50DB level.
5, Stepless Speed Control: PMSM motor driving fan blade, VFD step less peed control, easy to operate;
6, Waterproof/Dustproof: Protection level is IP55, waterproof in overall. The fan can be used in rainy/humid days and is easy to clean with water;
7, Modularization installation: The fan is modular design, which is suitable for carrying and easy to be installed.



Model numaber	Voltage (V)	Power (KW)	Speed  (rpm)	Blade  Diameter(meter)	Air Volume (m³/min)	Noise   (DB)	Blade Quality  (pcs)	Weight  (Kg)
GFP-200	220	0.9	250	2.0	1600	50	6	150
GFP-150	220	0.7	350	1.5	1000	50	6	100
