Небольшой режущий и фрезерный станок для хобби 7040 в 7045 в

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description



Product Description




Specification


The main performance characteristics:
Variable speed
Milling, drilling, boring, reaming and tapping
Head swivels 90 vertical
Micro feed precision
Adjustable gibs on table precision.
Strong rigidity, powerful cutting and precisely positioning.
Standard accessories:
Allen wrench
Drift
Spanner
Drill chuck rod
Screw-driver
Draw bar and gasket

Optional accessories:
Stand
Oil basin
Power feed attachment
Machine vice
Drill chuck
Milling cutter holder
Reducing sleeve
Mill chuck
Boring rod
Tapping electrical system
Coolant system

Product main technical Specifications:


ITEM
ZAY7032V
ZAY7040V
ZAY7045V
Drilling capacity
32mm
40mm
45mm
Max Face mill capacity
63mm
80mm
80mm
Max End mill capacity
20mm
32mm
32mm
Distance from spindle nose to table
400mm
400mm
400mm
Min.distance from spindle axis to column
285mm
285mm
285mm
Spindle travel
130mm
130mm
130mm
Spindle taper
M.T.3 or R8
M.T.4 or R8
M.T.4 or R8
Range of spindle speed(2 steps)
100-530,530-2800r.p.m,
100-530,530-2800r.p.m,
100-530,530-2800r.p.m,
Swivel angle of headstock (perpendicular)
±90°
±90°
±90°
Table size
800×240mm
800×240mm
800×240mm
Forward and backward travel of table
175mm
175mm
175mm
Left and right travel of table
500mm
500mm
500mm
Motor power(DC)
1.1KW
1.1KW
1.5KW
Voltage/Frequency
110V or 220V
110V or 220V
110V or 220V
Net weight/Gross weight
300kg/350kg
310kg/360kg
310kg/360kg
Packing size
770×880×1160mm
770×880×1160mm
770×880×1160mm
