| MAIN PARAMETER | UNIT | ZX50C |
| max. drilling diameter | mm | 50 |
| max. width of end milling | mm | 100 |
| max. vertical mill diameter | mm | 25 |
| max.diameter of boring | mm | 120 |
| max. tapping diameter | mm | M16 |
| spindle taper | MT4 | |
| distance from spindle end to table surface | mm | 38-430 |
| spindle speed range | rpm | 230-1825 |
| spindle travel | mm | 120 |
| table size | mm | 800x240 |
| table travel | mm | 400x230 |
| main motor power | kw | 1.5/2.2 |
| overall size | mm | 1100x970x1650 |
| net weight | kg | 550 |




Zaozhuang Shuomai Industrial and commercial Co., Ltd is a foreign-oriented enterprise engaged in the development, design, manufacture, sales and import and export of metal cutting machine tools. Metal cutting machine tools include two major categories, one is CNC lathe, CNC machine center, CNC drilling machine, CNC milling machine, the other is the ordinary machine tools, include lathe machine, radial drilling machine, vertical drilling machine, drilling milling machine, metal band saw, grinding machine, hydraulic machine, boring machine and so on, more than 100 kinds of specifications. Market coverage of the country and exported more than 30 countries and regions.
