HZP-C cosmetic capsule machine is the new production developed by our company in 2012,it is the small model of cosmetic capsule machine,it is easy to operate , automatic control technology, the whole set of equipment including a main engine and control syssterm a dryer, chemical rubbertank, batching tank, colloid mill and other needed
Main Engine
Die roll size 150mm X 250 mm Die roll speed 0-4 rpm Charge for a single plunger 0-1.5 ml Main Motor Power 0.55 Kw Machine Power 6 Kw Power supply 220 V 50 Hz Over dimension 2380mm X 985mm X 1982mm
Dryer
Basket Size Φ600mm x 900mm Control Central control system Electric spes 200V /50HZ/50HZ 1 PH Required power 90 W Main Motor 0.2Kw X 2 motors Pan Motor 0.2 Kw X 2 Fans Dimension 500mm X 400mm X 700mm Material SUS 316 for control area
Rolling Die
Material AL 7075 (Duralumin Injection segment 1 set Distribution plate 1 set Time gear 1 set
Capsule Dry and Trailer
Material PPE Dimension 760mm X 490mm X 55mm Capacity 2500 capsule Trailer Material SUS 304 Dimension 775mm X 510mm X 115mm Four casters Equipped on the bottom
Air Compressor
Material SUS 304 Dimension 420mm X 220MM X 360mm Weight 2 Kg Voltage 220 V / 50 Hz Power ≤320 W Air flow ≤3.3³/H
Gelatin Melting Tank
Material SUS 304 Dimension Φ400mm X 700mm Weight 40 Kg Power 1 Kw Voltage 220V / 2.2Kw Frequency 50 Hz / 60 Hz Max rate 16 rpm 9fixed Max temp 90--100℃ Max capa 30 liter *1 tan
Detailed Images
FAQ
About Our Machine and Company
Q: Are you a factory or a trading company A: We are a factory manufacturer for pharmaceutical equipment and soft capsule making machine we provide prefect OEM and after service.
Q: Where is you factory ? How can i visit your factory A: Our factory is located in Beijing City, near the airport, we are warmly welcome you visit our factory, we can pick you up as Beijing International Airport .
Q: How can I know the machine is designed for my product? A; You can sent the samples to us, the we will test it on machine
Q: How can I know your machine is designed for my product? A: If you don't mind, you can send u sample and we test it on the machine. During that time, we will take video and clearer picture for you. If chance, we can take video online and show u.
Q: How about your after sales service A: First, before the transportation , we offer the training course for your technical ,if he come to our factory, and next, after the transportation, we have 12 month warranty for the machine, and if you need we can sent our technical and engineer to your factory and help you with the equipment commissioning
Our Service
Before Transportation
Before the transportation , we offer the training course for your technical ,if he come to our factory, and next, after the transportation, we have 12 month warranty for the machine, and if you need we can sent our technical and engineer to your factory and help you with the equipment commissioning
After Transportation
We will take video and clearer picture for you. If chance, we can take video online and show you.Online video service ,24 hour technology support by mail or online.if you need we can sent our engineer to your palace.
